ReGen LIVE · 12G SDI + HDMI
ReGen LIVE Polystream 12G SDI+HDMI Encoder
One encoder for the 4K signal chain: a single 12G-SDI / HDMI input captures up to 4096×2160p60 and encodes it in 10-bit H.265 or H.264 with BT.2020 color at around 100 ms of latency. It streams over SRT, RTMP(S), RTSP, HLS, and UDP, records to USB 3.0 storage or TF card, and stays remotely manageable through RemoteGenius wherever it is racked.
- 4K DCI capture — 4096×2160p60 and 3840×2160p60 over 12G-SDI or HDMI
- 10-bit encoding with BT.2020 / BT.709 / BT.601 color, around 100 ms latency
- SRT, RTMP(S), RTSP, HLS, HTTP-FLV, UDP unicast / multicast transports
- On-board recording to USB 3.0 U-disk, SSD, or TF card with Samba access
- Remote management via RemoteGenius API (molfarMQ protocol)
- Resolution
- 4K60
- Codec
- H.265 / H.264
- Latency
- ~100 ms
- Power
- 10 W
Specifications
Full Technical Specifications
| Video I/O | |
|---|---|
| Inputs | 1× 12G-SDI / HDMI |
| Supported Resolutions | 4096×2160p60, 3840×2160p60, 2560×1440p144, 1080p60/50, 1080i60/50, 720p60/50, 720×576i, 720×480i |
| Color Gamut | BT.2020 / BT.709 / BT.601 |
| Bit Depth | 10 |
| Audio I/O | |
| Input | 1× HDMI embedded, 1× 3.5 mm analog |
| Output | — |
| Compression | AAC / AAC+ / MP3 / MP2 / AC3 |
| Audio Sample Rate | 44.1 / 48 kHz |
| Bit Depth | 24-bit |
| Audio Bitrate | 32 / 48 / 64 / 96 / 128 / 160 / 192 / 384 kbps |
| Video Processing | |
| Compression | H.265 (HEVC), H.264 (AVC) |
| Encoding Output | Up to 2160p60 |
| Supported Bitrate | 0.32 Mbps – 64 Mbps |
| Bitrate Control | CBR / AVBR / CVBR / Strong CBR |
| GOP Length | 5 – 300 |
| Advanced | Video clip, brightness, contrast, RGB adjustment |
| Latency | ~100 ms |
| Video Transport Protocols | SRT, HTTP, RTSP, RTMP(S), HLS, FLV, UDP unicast / multicast |
| File Recording Types | NTFS / exFAT / FAT32 |
| File Recording Media | USB 3.0 U-disk, SSD, or TF card |
| On-Screen Display (OSD) | |
| Images or Text | Up to 3 |
| Advanced | 1 text scroll, time overlay |
| Protocol Support | |
| Network Protocols | TCP/IP, UDP, HTTP, DHCP, NTP |
| Network File Access | Samba |
| Remote Management | RemoteGenius API (molfarMQ protocol) |
| Interfaces | |
| Web UI | Yes |
| CGI | Yes |
| Network | |
| Ethernet | 1 Gbit (1000Base-T) |
| Wireless | — |
| USB | 1× USB 3.0 (recording media) |
| Internal Modems | — |
| External Modems | — |
| Antennas | — |
| Power | |
| Power Input | 12 V DC, 2 A |
| Internal Battery | — |
| Power Consumption | 10 W |
| Physical Attributes | |
| Dimensions | 170 × 104 × 38 mm | 6.69″ × 4.09″ × 1.50″ |
| Weight | 600 g net | 1.2 kg gross |
| Construction | Aluminium alloy |
| Cooling | Active (fan) |
| General | |
| Operating Temperature | 0–45 °C (operating), −20 to +80 °C (storage) |
| Humidity | — |
| IP Rating | — |
| Compliance | |
| FCC | Yes |
| CE | Yes |
Order Now
Ready to Deploy ReGen LIVE 12G SDI+HDMI?
Tell us how many 4K channels you run and where the encoders will sit — studio rack, venue, or a remote site — and we will come back with pricing, lead time, and integration support.
Working in a 1080p 3G-SDI chain instead? See the ReGen LIVE 3G SDI encoder.
